Make a flame red!
- Put on protective gloves and eyewear.
- Conduct the experiment on the plastic tray.
- Keep hair and flammable objects away from flame.
- Do not allow chemicals to come into contact with the eyes or mouth.
- Keep young children, animals and those not wearing eye protection away from the experimental area.
- Store this experimental set out of reach of children under 12 years of age.
- Clean all equipment after use.
- Make sure that all containers are fully closed and properly stored after use.
- Ensure that all empty containers are disposed of properly.
- Do not use any equipment which has not been supplied with the set or recommended in the instructions for use.
- Do not replace foodstuffs in original container. Dispose of immediately.
- In case of eye contact: Wash out eye with plenty of water, holding eye open if necessary. Seek immediate medical advice.
- If swallowed: Wash out mouth with water, drink some fresh water. Do not induce vomiting. Seek immediate medical advice.
- In case of inhalation: Remove person to fresh air.
- In case of skin contact and burns: Wash affected area with plenty of water for at least 10 minutes.
- In case of doubt, seek medical advice without delay. Take the chemical and its container with you.
- In case of injury always seek medical advice.
- The incorrect use of chemicals can cause injury and damage to health. Only carry out those experiments which are listed in the instructions.
- This experimental set is for use only by children over 12 years.
- Because children’s abilities vary so much, even within age groups, supervising adults should exercise discretion as to which experiments are suitable and safe for them. The instructions should enable supervisors to assess any experiment to establish its suitability for a particular child.
- The supervising adult should discuss the warnings and safety information with the child or children before commencing the experiments. Particular attention should be paid to the safe handling of acids, alkalis and flammable liquids.
- The area surrounding the experiment should be kept clear of any obstructions and away from the storage of food. It should be well lit and ventilated and close to a water supply. A solid table with a heat resistant top should be provided
- Substances in non-reclosable packaging should be used up (completely) during the course of one experiment, i.e. after opening the package.
FAQ and troubleshooting
It turns out that calcium nitrate is a very hygroscopic substance – it loves interacting with the water in the surrounding air, and as a result, its crystals tend to stick to each other and to the walls of the bottle.
Use a wooden stick to knock the calcium nitrate loose from the bottle walls and break apart any lumps.
Carefully study the information provided in the experiment set. Inside the box is a sticker detailing how to use the thermostickers provided in each box when dealing with heated objects.
Attach the sticker to the surface you are going to heat. As long as the surface is safe to touch, the sticker will remain black. When the surface is heated, the sticker will turn yellow. Do not touch a surface unless the sticker attached to it is black.
There are two possible solutions to this problem. First, you can try waiting a bit. The mixture might burn slowly at first, but gain speed and intensity after 10-20 seconds. And if the mixture stops burning without creating a bright orange flame, try mixing the components more thoroughly (check step 2 in the experiment card) and then repeating steps 3-4.
Calcium nitrate tetrahydrate crystals contain water, which will disrupt the experiment. Heat the crystals to force the water to evaporate.
When the calcium nitrate dries out completely, add some solid fuel.
To prepare for the reaction, put some of the mixture into the stove.
To initiate the reaction, set the mixture on fire.
Dispose of solid waste together with household garbage.
Many nitrates, such as calcium nitrate Ca(NO3)2 , are good combustion companions to fuels such as hexamethylene-tetramine. When heated , nitrates decompose and release oxygen O2 , oxygen reacts with the fuel to produce even more heat , and so on. When orderly calcium nitrate crystals decompose, some calcium ions (calcium atoms with some electrons missing) can take off and fly with the flame.
Not only are these ions expelled into the air, they also receive a lot of heat energy . This energy is absorbed by the ion's electrons. Eventually, they release this energy in the form of light . The color of this light depends on the type of ion releasing it. For calcium ions it happens to be brick-red, and that's why the flame you see has this glamorous red tint.
Heated ions’ tendency to release light of a particular color might come in handy if you ever need to figure out if a certain element is present in a sample. Copper ions will tint a flame green, sodium ions—yellow, and so on. Perhaps you can guess how fireworks come to have all sorts of colors in their flames?
What happens to the calcium nitrate?
Calcium nitrate, also known as Norwegian saltpeter, has a formula of Ca(NO3)2. However, this substance, like many others, can exist in the form of crystals that contain a number of water molecules. Such substances are usually called crystallohydrates.
These crystals contain four water molecules for every one calcium nitrate species, so the composition of the substance is actually Ca(NO3)2·4H2O. We need to get rid of this water, so we heat the substance to force the water to evaporate.
Incidentally, it is the water molecules that cause the calcium nitrate crystals to clump.
You will learn more about the key process below, but in brief: the water molecules would absorb a lot of energy needed for the main reaction (the combustion of the mixture of calcium nitrate and solid fuel), slowing and subduing the result.
Why do I need to mix the solid fuel and dried calcium nitrate?
We mix these two solids to make them act more effectively. If both calcium nitrate and solid fuel are spread evenly throughout the mixture, the burning will occur equally well everywhere.
What is solid fuel and how does it burn?
Solid fuel is a substance known as urotropine or hexamethylenetetramine. It consists of 6 carbon C, 12 hydrogen H, and 4 nitrogen N atoms - C6H12N4.
It burns readily while producing almost no smoke or smell, is not afraid of moisture (unlike burning wood), and yields a lot of heat when combusting. These attributes make it popular for use in tourism, camping, and some military contexts, especially in cases in which it is necessary to heat food or warm up quickly in tricky weather conditions.
What happens to the dried calcium nitrate?
Actually, it is the solid fuel that burns, releasing a lot of heat. Usually, when we say that a substance burns, we mean that it reacts intensively with oxygen from the ambient air.
The calcium nitrate Ca(NO3)2 does not burn, but rather decomposes when heated to yield two substances – oxygen and calcium nitrite:
2Ca(NO3)2 → O2↑ + Ca(NO2)2
The oxygen released throughout the mixture facilitates the burning of the solid fuel, which allows the fuel to produce even more heat.
Some calcium ions (calcium atoms with two electrons missing) can vaporize into the flame, tinting it bright orange.
The chemical reaction we observe produces a large amount of energy. The aforementioned calcium ions Ca2+ are not only transported into the air but also receive a lot of heat energy.
This amount is sufficient to excite some of the calcium ions’ electrons. For a time, these electrons contain more energy than normal. They soon release this energy in the form of light.
Calcium ions produce a bright orange to brick-red light. The color of the light depends on the nature of the ion releasing it. For example, the flames containing copper ions Cu2+ will be tinted green.
